Repair Cognex DMR-152 Fixed Mount Barcode Reader

Reads 1-D and stacked codes, omnidirectional 1-D codes, and 2-D codes.

Repair

$2,647.00
Availability
  • Usually ships in 2-3 weeks
Part Number
  • DMR-152REP
Manufactured
Product Specs

Features

  • 1DMax & 2DMax algorithms
  • 1280 x 960 global shutter
  • 1/3 CMOS image sensor
  • 45fps acquisition
  • 2 green aimer LEDs
  • 2 opto-isolated discrete inputs
  • 2 opto-isolated discrete outputs
  • 5 status LEDs and beeper
  • Power:
    • 5 to 26VDC, 2.5W (USB bus power option)
    • DB-15 pig tail cable, pin compatible to DM100
  • <2.5W (USB) power consumption
  • RS-232 and USB interface communication
  • Aluminum material
  • IP-65 protection
  • RoHS certified
  • Approvals:
    • USA FCC Part 15, Class A
    • Canada ICES-003
    • European Community EN55022:2006 +A1:2007, Class A, EN55024:1998 +A1:2001 +A2:2003, EN60950

The Cognex DMR-152 Fixed Mount Barcode Reader uses 1DMax with Hotbars II technology to decode damaged or poorly printed 1-D barcodes as quickly as 45 decodes per second. 2DMax provides reliable 2-D code reading independent of code quality, printing method, or the surface that the codes are marked on, and with PowerGrid technology, can locate and read 2-D codes that exhibit significant damage to or complete elimination of the finder pattern, clocking patter, or quiet zone.

DataMan 150/260 Series models offer straight or right-angled configurations to fit into tight spaces. In-line and ninety degree configurations eliminate the need for equipment redesign, and complicated optical paths with mirrors.
