Repair GE-Emerson IC670ALG320 Field Control Analog Output Module

Grouped, 4 current/voltage points.

Repair

$1,380.00
Availability
  • Usually ships in 3-5 business days

New Surplus

$2,300.00
Availability
  • Out of Stock

Remanufactured

$1,725.00
Availability
  • Out of Stock
Part Number
  • IC670ALG320REP
Manufactured
Product Specs

Features

  • 1 LSB resolution value
  • 20 to 29VDC power supply range, 5% max. ripple
  • 24V power input current
    • 80mA typical standby (no output)
    • 180mA (including loop current) max. operating current
  • 1.5 to 4.3W module power dissipation
  • Temperature coefficient:
    • +/-0.002% of value per degree Celsius, typical
    • +/-0.005% of value per degree Celsius, max.
  • 1500VAC for 1min isolation to ground and logic, 250VAC continuous
  • 51mA max. current drawn from BIU power supply
  • 12bits digital resolution, typical

The GE-Emerson IC670ALG320 Field Control Analog Output Module includes output channels that each provide a span of 4 to 20mA and 0 to 12.5V by adding jumper on the I/O Terminal Block. Default scaling is 0 to 20,000. Scaling can be changed in configuration to match the output used or to engineering units.

The same 24V power supply used for the Bus Interface Unit can provide loop power to the outputs in most cases. If module to module (or Bus Interface Unit) isolation is required, separate power supply(s) must be used. The most common application would have the loop supply local at the module, driving multiple isolated transducers, isolated analog inputs, or differential analog inputs.

An LED, visible through the transparent portion of the module loop, indicates whether field and backplane power are present.
