Remanufactured Allen-Bradley 1746-IO8 SLC 500 Combination Input and Output Module

4 inputs, outputs, and points per common.

Remanufactured

$112.00
Availability
  • 3 in stock
  • Additional 1 ready to ship within 2-3 days

Repair

Call for pricing
Availability
  • Usually ships in 2-3 weeks
Part Number
  • 1746-IO8RMN
Manufactured
Product Specs

Features

  • Voltage category:
    • 120VAC (inputs)
    • 100/120VAC (relay contact outputs)
  • Operating voltage range:
    • 85 to 132VAC @ 47 to 63Hz (inputs)
    • 5 to 265 VAC @ 47 to 63Hz / 5 to 125 VDC (outputs)
  • Backplane current:
    • 60mA at 5VDC
    • 45mA at 24VDC
  • Watts per point:
    • 0.27W (input)
    • 0.133W (output)

The Allen-Bradley 1746-IO8 SLC 500 Combination Input and Output Module is a digital I/O module with a combination of 120VAC inputs and relay contact outputs. Terminals have self-lifting pressure plates that accept two 14 AWG (2mm2) wires. LED indicators on the front of each module display the status of each I/O point.
