Remanufactured GE-Emerson IC200ALG430 Analog Mixed Module

12-bit, four analog current inputs, two analog current outputs.

Remanufactured

$408.80
Availability
  • 5 in stock
  • Additional 4 ready to ship within 2-3 days

Repair

Call for pricing
Availability
  • Usually ships in 3-5 business days

For on-site repair and support, call us at 1-704-448-2212 or email sales@qualitrol.com.

Part Number
  • IC200ALG430RMN
Manufactured
Product Specs

Features

  • Channels:
    • 4 differential inputs, one group
    • 2 single-ended outputs, one group
  • 50mA maximum backplane current consumption at 5V output
  • Output default configuration parameters
  • Loss of user side power diagnostics
  • 18 to 30VDC recommended power supply range (including ripple)

The GE-Emerson IC200ALG430 Analog Mixed Module uses a CPU or Network Interface Unit for intelligent processing. The module provides four words of analog input data and receives two words of analog output data. The green FLD PWR LED indicates the presence of user-side power for the analog field-side circuits. The green OK LED is on when backplane power is present to the module. The module can be set up with a jumper for the outputs to either hold their last states or default if backplane power or communications are interrupted or the PLC is stopped. External user power must remain uninterrupted. Outputs remain in the default or last state until the module receives different output data from the backplane, or until field power is removed.

When software-configured, inputs can be configured to hold last state or report a selectable value. When the module is autoconfigured using a CPU or NIU that is version 2.x or later, inputs default to 0. If the CPU or NIU is version 1.5 or earlier, the input default matches the jumper-configured output default (0 or Hold Last State).
