Remanufactured GE-Emerson IC200MDL744 VersaMax Negative Logic Discrete Output Module

Provides two groups of 16 discrete outputs.

Remanufactured

$246.40
Availability
  • 4 in stock

Repair

Call for pricing
Availability
  • Usually ships in 3-5 business days

For on-site repair and support, call us at 1-704-448-2212 or email sales@qualitrol.com.

Part Number
  • IC200MDL744RMN
Manufactured
Product Specs

Features

  • Isolation:
    • 250VAC continuous; 1,500VAC for 1min user input to logic (optical) and frame to ground
    • 250VAC continuous; 1,500VAC for 1min group-to-group
  • One green LED per point shows individual point on/off state
  • FLD PWR LED indicates field power is present
  • OK LED indicates backplane power is present
  • 5V output: 140mA max. backplane current consumption
  • External power supply:
    • 5VDC-TTL mode: 4.75 to 5.25VDC, 5VDC nominal
    • 12/24VDC mode: 10.2 to 30VDC, 12/24VDC nominal

The GE-Emerson IC200MDL744 VersaMax Negative Logic Discrete Output Module includes negative or sinking type outputs. They switch the loads to the negative (return) side of the DC supply and thus receive current from the loads.

An external DC power supply must be provided to switch power to the loads. Intelligent processing for this module is performed by the CPU or NIU. The module receives 32 bits of discrete output data.
