Remanufactured GE-Emerson IC200MDL750 VersaMax Positive Logic Discrete Output Module

Provides two groups of 16 discrete outputs.

Remanufactured

Call for pricing
Availability
  • 3 in stock

Repair

Call for pricing
Availability
  • Usually ships in 3-5 business days

For on-site repair and support, call us at 1-704-448-2212 or email sales@qualitrol.com.

Part Number
  • IC200MDL750RMN
Manufactured
Product Specs

Features

  • Isolation:
    • 250VAC continuous; 1,500VAC for 1min user input to logic (optical) and frame to ground
    • 250VAC continuous; 1,500VAC for 1min group-to-group
  • One LED per point shows individual point on/off state
  • FLD PWR LED indicates field power is present
  • OK LED indicates backplane power is present
  • 5V output: 90mA max. backplane current consumption
  • 10.2 to 30VDC, 12/24VDC nominal

The GE-Emerson IC200MDL750 VersaMax Positive Logic Discrete Output Module includes positive or sourcing type outputs. They switch the loads to the positive side of the DC supply and thus supply current to the loads.

12V output functionality requires module version -B or higher.

An external DC power supply must be provided to switch power to the loads. Intelligent processing for this module is performed by the CPU or NIU.
