Remanufactured GE-Emerson IC660TBA101 Genius Terminal Assembly

I/O module with 6 RTD-compatible input channels which are split into 3 isolated groups of 2 inputs each.

Remanufactured

$488.00
Availability
  • Out of Stock

Repair

$341.60
Availability
  • Usually ships in 3-5 business days

For on-site repair and support, call us at 1-704-448-2212 or email sales@qualitrol.com.

Part Number
  • IC660TBA101RMN
Manufactured

Features

  • 7 Watts maximum heat dissipation
  • 115 Volts AC
  • 125 Volts DC

The GE-Emerson IC660TBA101 Genius Terminal Assembly offers group-to-group isolation of 300 Volts, with each input channel on the I/O block being compatible with copper, platinum, or nickel RTDs.

For CPU reporting, engineering units such as counts, tenths of ohms, tenths of degrees Fahrenheit, and tenths of degrees Celsius are employed. Additionally, the IC660BBA101 module allows for configuration of additional features, such as linearization, alphatype, RTD resistance, and input filter time settings.

The IC660BBA101 module comes pre-calibrated from the factory, eliminating the need for further calibration. This module is compatible and can be used with Series 90-70 PLCs, Series Six PLCs, and Series Five PLCs.
