Repair GE-Emerson IC200EBI001 VersaMax Ethernet Network Interface Unit

Repair

Call for pricing
Availability
  • Usually ships in 3-5 business days

Remanufactured

$682.08
Availability
  • 3 in stock
  • Additional 13 ready to ship within 2-3 days

For on-site repair and support, call us at 1-704-448-2212 or email sales@qualitrol.com.

Part Number
  • IC200EBI001REP
Manufactured
Product Specs

Features

  • 10Base-T or 100Base-TX, auto-negotiated Ethernet network data rate
  • 1,024 bytes max. I/O data
  • Up to 512 bytes of inputs or 512 bytes of outputs
  • 128 bytes max. fault data
  • LEDs:
    • Power LED indicates presence of input power
    • OK LED indicates health of the ENIU
    • Faults LED indicates presence of faults
    • LAN LED indicates health of Ethernet network
    • Stat LED solid green indicates Modbus connection present or receipt of EGD exchanges
    • Stat LED flashing amber indicates invalid IP address
  • Power consumption:
    • +5V@175mA
    • +3.3V@425mA

The GE-Emerson IC200EBI001 VersaMax Ethernet Network Interface Unit is an Ethernet slave module that acts as a controller for a set of I/O modules. Power for module operation is provided by a power supply that installs directly on the NIU. The card has a default IP address of 195.0.0.x, where x is selected on the rotary switches.
