Repair GE-Emerson IC200MDL331 VersaMax Discrete Isolated Output Module

Provides 8 isolated discrete outputs.

Repair

Call for pricing
Availability
  • Usually ships in 3-5 business days

Remanufactured

Call for pricing
Availability
  • Out of Stock

For on-site repair and support, call us at 1-704-448-2212 or email sales@qualitrol.com.

Part Number
  • IC200MDL331REP
Manufactured
Product Specs

Features

  • Isolation:
    • 250VAC continuous; 1,500VAC for 1min user input to logic (optical) and frame to ground
    • 250VAC continuous; 1,500VAC for 1min point-to-point
  • One LED per point shows individual point on/off state
  • OK LED indicates backplane power is present
  • 5V output; 85mA max. backplane current consumption
  • 85 to 132VAC (47 to 63Hz), 120VAC nominal external power supply

The GE-Emerson IC200MDL331 VersaMax Discrete Isolated Output Module includes intelligent processing performed by the CPU or NIU. The module receives 8 bits of discrete output data. An external 120VAC power supply must be provided to switch power to the loads.
