Repair GE-Emerson IC200MDL632 VersaMax Discrete Isolated Input Module

Provides 16 discrete isolated inputs.

Repair

Call for pricing
Availability
  • Usually ships in 3-5 business days

Remanufactured

Call for pricing
Availability
  • 2 in stock

For on-site repair and support, call us at 1-704-448-2212 or email sales@qualitrol.com.

Part Number
  • IC200MDL632REP
Manufactured
Product Specs

Features

  • Isolation:
    • 250VAC continuous; 1,500VAC for 1min user input to logic (optical) and frame to ground
    • 250VAC continuous; 1,500VAC for 1min point-to-point
  • One LED per point shows individual point ON/OFF status
  • OK LED indicates backplane power is present
  • 80mA max. backplane current consumption (5V output)
  • No external power supply
  • Input response times configuration parameters

The GE-Emerson IC200MDL632 VersaMax Discrete Isolated Input Module includes inputs that can be either positive logic inputs that receive current from input devices and return the current on the return, or negative logic inputs that receive current from the return and return current to the input device. Input devices are connected between the input terminals and return terminals.

Power for the module's operation comes from the backplane. Intelligent processing for the module is performed by the CPU or NIU.
