Repair GE-Emerson IC660TSA020 Genius Terminal Assembly

The GE-Emerson IC660TSA020 Genius Terminal Assembly is engineered with four independent input circuits and two output circuits. There are two block versions of this module available: one with a 115 Volts AC voltage variant and the other with a 24/48 Volts DC voltage variant. These two versions are nearly identical, differing only in their power supply configurations. Each individual circuit of the module is capable of accepting and providing signals within various voltage and current ranges. To interface with the block and incorporate loop devices with diverse signal ranges, additional resistance can be employed.

The module features a 12-bit resolution that updates every 4 milliseconds. Additionally, the IC660TSA020 module utilizes a diagnostics feature, which enables it to detect underrange and overrange situations. At 25 degrees Celsius, the thermal drift of the module is 10 PPM (parts per million) per degree Celsius, with a maximum of 40 PPM per degree Celsius. The module also boasts an absolute accuracy of 0.2% at full scale.
