Remanufactured GE-Emerson IC698CMX016 Rx7i Control Memory Xchange Module

16MB reflective memory with parity.

Remanufactured

Call for pricing
Availability
  • Out of Stock

Repair

$6,000.00
Availability
  • Usually ships in 3-5 business days

For on-site repair and support, call us at 1-704-448-2212 or email sales@qualitrol.com.

Part Number
  • IC698CMX016RMN
Manufactured
Product Specs

Features

  • 6.299in (W) x 9.187in (H)
  • Dynamic packet size, automatically controlled by Memory Xchange module
  • 16MB SDRAM user memory
  • +5VDC operating voltage (from power supply)
  • 1.8 Amps current requirements
  • Connectors:
    • Fiber optic LC type, conforms to IEC 61754-20
    • Zirconium ceramic ferrule
    • Insertion loss: 0.35dB (max)
    • -30dB return loss
    • -4 to 185°F temperature range
  • Software configuration of all node parameters (no jumper or switch settings required)
  • High-speed easy-to-use 2.12 Gbaud fiber-optic network
  • No Rx7i CPU processing required to operate the network
  • Network-compatible with VMIC 5565 family of reflective memory devices
  • Connection with multimode fiber up to 985.25ft
  • Dynamic packet sizes of 4 to 64 bytes, controlled by the module
  • Max. network transfer rate: 43MB/s (4 byte packets) to 174MB/s (64 byte packets)
  • Programmable VMEbus interrupt output
  • Four general-purpose network interrupts with 32 bits of data each
  • Network error detection
  • Up to 256 nodes per network
  • Redundant transfer mode operation (reduces chance of a data packet being dropped from the network)
  • Configurable network memory offset (allows nodes to be assigned on a network in groups according to the 16MB segment in the network address space used)

The GE-Emerson IC698CMX016 Rx7i Control Memory Xchange Module provides deterministic sharing of data among PLCs and other computing devices on a high-speed fiber optic network, using reflective memory technology. A reflective memory network can contain up to 256 nodes. Each node in the network can be any reflective memory device that is compatible with the 5565 family. When data is written to one node, all nodes on the network are automatically updated with the new data.

Each node in the reflective memory network is connected in a daisy-chained loop using fiber optic cables. The transmitter of the first node is tied to the receiver of the second. The transmitter of the second node is tied to the receiver of the third node, and so on, until the loop is completed back at the receiver of the first node.

A PACSystems RX7i main rack supports a maximum of four Memory Xchange modules.
