Remanufactured GE-Emerson IC695ALG106 PACSystems RX3i Isolated Analog Input Module

Six isolated inputs individually configurable to receive voltage and current signals .

Remanufactured

Call for pricing
Availability
  • Out of Stock

Repair

$1,296.96
Availability
  • Usually ships in 3-5 business days

For on-site repair and support, call us at 1-704-448-2212 or email sales@qualitrol.com.

Part Number
  • IC695ALG106RMN
Manufactured
Product Specs

Features

  • 6 isolated inputs
  • +/- 10V, 0 to 10V, +/- 5V, 0 to 5V, 1 to 5V voltage range
  • 0-20 mA, 4-20 mA and +/-20 mA cuurent range

The GE-Emerson IC695ALG106 PACSystems RX3i Isolated Analog Input Module features a total of six (6) isolated analog input channels, and is capable of accommodating an array of voltage and current standard signals, including +/- 10V, 0 to 10V, +/- 5V, 0 to 5V, 1 to 5V, as well as 0-20 mA, 4-20 mA, and +/-20 mA signals for voltage and current.

Configurable filter choices, specifically 8Hz, 12Hz, 16Hz, 40Hz, 250Hz, and 1000Hz, are accessible for every input channel. Regardless of the chosen filter setting, the module maintains a consistent scan time of 1ms, although the settling times may differ according to the configured filter options. The module offers a calibration accuracy of 0.1% within the range at 25°C, and this accuracy extends to 0.2% across the entire temperature spectrum.
