Repair GE-Emerson IC695ALG306 RX3i Isolated Thermocouple Input Module
Module featuring 6 individually isolated thermocouple input channels and fault status reporting.
For on-site repair and support, call us at 1-704-448-2212 or email sales@qualitrol.com.
- IC695ALG306REP
- By GE-Emerson
Overview
Features
- 6/12 Individually isolated channels
- 15 milliseconds to 120 milliseconds update rate
- 400 milliamps at 3.3 Volts or 150 milliamps at 5 Volts internal power
Description
The GE-Emerson IC695ALG306 RX3i Isolated Thermocouple Input Module is equipped with six distinct thermocouple input channels, each isolated individually. These channels accommodate input voltage ranges of either +/-150 millivolts or +/-50 millivolts. Compatibility is extended to various thermocouple types, including B, C, E, J, K, N, R, S, or T.
Each individual thermocouple type has its own operational temperature range. Specifically, the temperature ranges for each type are as follows: Type B ranges from 300 to 1820 degrees Celsius, Type C spans from 0 to 2315 degrees Celsius, Type E covers a range of -270 to 1000 degrees Celsius, Type J operates within -210 to 1200 degrees Celsius, Type K operates in the range of -270 to 1372 degrees Celsius, Type N spans from -210 to 1300 degrees Celsius, Type R covers 0 to 1768 degrees Celsius, Type S also covers 0 to 1768 degrees Celsius, and Type T operates within -270 to 400 degrees Celsius. Additionally, this module offers a resolution ranging from 11.5 to 16 bits.
