Repair Allen-Bradley 1747-L514 SLC 500 Controller Processor

4K memory (words).

Repair

Call for pricing
Availability
  • Usually ships in 2-3 weeks

Remanufactured

$605.92
Availability
  • 3 in stock
  • Additional 41 ready to ship within 2-3 days
Part Number
  • 1747-L514REP
Manufactured
Product Specs

Features

  • Backplane current:
    • 90mA @ 5V
    • 0mA @ 24V
  • 7,880 max. digital I/O
  • 3 max. local chassis/30 max. local slots
  • DH-485 Slave onboard communications
  • Compatible with EEPROM memory modules
  • RSLogix 500 programming
  • 52 programming instructions
  • 8ms/K typical scan time
  • 20ms to 3s program scan hold-up time following power loss (depending on power supply loading)
  • 4μs bit execution (XIC)

The Allen-Bradley 1747-L514 SLC 500 Controller Processor is compatible with a DH-485 device as a receiver (slave) in the programming channel. The chassis must be powered off before removing or installing the processor to avoid harm to the user or damage to the equipment. The processor's battery may be replaced while the processor is on.

The processor is designed for use in small and medium automation applications, and supports implementation of extended I/O and remote I/O chassis via a supported communication adapter.
