Remanufactured GE-Emerson IC693MDL733 12/24VDC Negative Logic 0.5 Amp Output Module

Provides 8 output points in one group with a common power output terminal.

Remanufactured

Call for pricing
Availability
  • Out of Stock

Repair

Call for pricing
Availability
  • Usually ships in 3-5 business days

For on-site repair and support, call us at 1-704-448-2212 or email sales@qualitrol.com.

Part Number
  • IC693MDL733RMN
Manufactured
Product Specs

Features

  • 12 to 24VDC output voltage range (+20%, -15%)
  • 1,500V isolation between field side and logic side
  • Output current:
    • 0.5 Amps max. per point
    • 2 Amps max. per common
  • Output characteristics:
    • 0.5V max. output voltage drop
    • 1mA max. off-state leakage
    • 2ms max. On and Off response time
  • 50mA power consumption (all outputs on) from 5V bus on backplane

The GE-Emerson IC693MDL733 12/24VDC Negative Logic 0.5 Amp Output Module sinks current from the loads to the user common or negative power bus. The output device is connected between the positive power bus and the module output. The output characteristics are compatible with a wide range of user-supplied load devices, such as: motor starters, solenoids, and indicators.  Power to operate  the field devices must be supplied by the user.

LED indicators which provide the ON/OFF status of each point are located at the top of the module. This LED block has two horizontal rows with eight green LEDs in each row; the top row labeled A1 through 8 (points 1 through  8) is used by this module. An insert goes between the inside and outside surface of the hinged door. The surface  towards the inside of the module (when the hinged door is closed) has circuit wiring information, and circuit identification information can be recorded on the outside surface. The outside left edge of the insert is color-coded blue to indicate a low-voltage module. There are no fuses on this module.

This module can be installed in any I/O slot of a 5 or 10-slot baseplate  in a Series 90-30 PLC system.
